Kawasaki Z 1000 SX






Specifications

Model: Kawasaki Z 1000 SX
Year: 2011
Category: Sport

Engine and transmission
Displacement: 1043.00 ccm (63.64 cubic inches)
Engine type: In-line four, four-stroke
Power: 136.11 HP (99.4 kW)) @ 9600 RPM
Torque: 110.00 Nm (11.2 kgf-m or 81.1 ft.lbs) @ 7800 RPM
Compression: 11.8:1
Bore x stroke: 77.0 x 56.0 mm (3.0 x 2.2 inches)
Valves per cylinder: 4
Fuel system: Injection. 38 mm x 4 (Keihin) with oval sub-throttles
Fuel control: DOHC
Lubrication system: Forced lubrication, wet sump
Cooling system: Liquid

Transmission type,
final drive: Chain
Clutch: Wet mDouble disk, manual
Driveline: Sealed chain
Chassis, suspension, brakes and wheels
Frame type: Aluminium twin-tube
Rake (fork angle): 24.5°
Trail: 102 mm (4.0 inches)

Front suspension: 41 mm inverted fork with stepless compression and rebound damping and spring preload adjustability
Front suspension travel: 120 mm (4.7 inches)
Rear suspension: Horizontal Back-link, gas-charged, with stepless rebound damping and cam-style spring preload adjustability
Rear suspension travel: 138 mm (5.4 inches)
Front tyre dimensions: 120/70-ZR17
Rear tyre dimensions: 190/50-ZR17
Front brakes: Double disc. Optional anti-lock braking
Front brakes diameter: 300 mm (11.8 inches)
Rear brakes: Single disc
Rear brakes diameter: 250 mm (9.8 inches)

Physical measures and capacities
Dry weight: 228.0 kg (502.7 pounds)
Power/weight ratio: 0.5970 HP/kg
Seat height: 820 mm (32.3 inches) If adjustable, lowest setting.
Overall height: 1,170 mm (46.1 inches)
Overall length: 2,105 mm (82.9 inches)
Overall width: 790 mm (31.1 inches)
Ground clearance: 135 mm (5.3 inches)
Wheelbase: 1,445 mm (56.9 inches)
Fuel capacity: 19.00 litres (5.02 gallons)
Other specifications
Starter: Electric
